Features:

With over 30 years of expertise in forklift manufacturing, Hangcha has combined proven craftsmanship with the latest technologies to create the XF Series. Designed through extensive research and development, the XF Series delivers superior efficiency, environmental responsibility, operator comfort, reliability, and safety. It is a comprehensive solution that meets the demands of modern businesses, balancing the needs of the environment, operators, and owners alike.

Specifications

Parameter	Value
Manufacturer	Hangcha
Model	FP30C
Tire Type	Pneumatic
Featured Attribute	N/A
Power/Fuel Type	LPG
Electrical System Voltage	12
Horsepower (hp)	61
Max Capacity (lbs.)	6000
Max Travel Speed Empty (mph)	11.1
Lift Speed Loaded (fpm)	88.6
Max Gradeability Loaded (%)	25
Length to Fork Face (in.)	107.5
Overall Height Collapsed (in.)	80.7
Overall Width (in.)	48.2
Overall Length (in.)	N/A
Lift Height (in.)	163.2
Turn Radius Inside (deg/in)	92.7
Wheelbase (in.)	66.9



Product Features

• Transmission & Power System

Suspended transmission, oil cooler, hydraulic oil filter, traction device

Dynamic load sending control valve (Diesel IC), tilt cylinder self-locking valve

• Steering & Control

Full hydraulic power steering, smaller diameter steering wheel / adjuster of steering wheel

Suspension pedal, integrated combination switch / cable parking brake

• Operator Comfort & Safety

Standard seat, suspension seat, skidproof pedal, rubber pedal, engine hood spring

Operator presence system, fire extinguisher, rear grip handle, customized color

• Visibility & Lighting

Standard wide view duplex mast, mast speed limiting valve, mast buffer devices

LED headlamp, high-efficient LED rear lights, front/rear working light, strobe light

• Cooling & Filtration

Big capacity aluminum radiator / copper radiator, radiator screen, little tank

Whirlwind air cleaner, safety filter, oil-water separator warning, air pre-cleaner

• Monitoring & Indicators

LCD display, neutral switch, fuel gauge, water temperature gauge, time meter

Engine fuel pressure warning, transmission oil pressure warning, pre-heat indicator, charging indicator

• Customization & Options

Full cabin with heater, front window with wiper, waterproof cover on the guard

Solid pneumatic tires / non-mark tire, wider fork carriage, wider load back rest, special forks

LPG swing out / swing down metal bracket, auxiliary hydraulic valve, electro-hydraulic proportional control system
