Vendor: LIUGONG
915E Excavator
Regular price
$99,999,999.00
Sale price
$99,999,999.00
Description
Description
Features:
The 915E touts options for auxiliary hydraulic piping include bi-directional variable high flow lines, an additional line for rotating attachments and also a single acting line. The quick coupler further ensures you get the most out of your machine by easily switching between a wide range of attachments to suit any application.
Specifications
| Category | Parameter | Detail |
| ENGINE | Emissions rating | EPA Tier 4 Final / Stage IV |
| Make | Cummins | |
| Model | QSB4.5 | |
| Gross power | 121 hp (90 kW) @ 2,200 rpm | |
| Net power | 113 hp (84.3 kW) @ 2,200 rpm | |
| Peak torque | 347 lb - ft @ 1,500 rpm（470 N·m @ 1,500 rpm） | |
| Number of cylinders | 4 | |
| Displacement | 275 in³ (4.5 L) | |
| DRIVE AND BRAKES | Max. travel speed | High: 3.7 mph (6.0 km/h); Low: 2.2 mph (3.5 km/h) |
| Max. drawbar pull | 27,876 lbf (124 kN) | |
| UNDERCARRIAGE | Shoe width, triple grouser | 24 in (600 mm) |
| Track shoe each side | 46 | |
| Bottom rollers each side | 7 | |
| Top rollers each side | 1 | |
| HYDRAULIC SYSTEM | Main pumps total flow | 2 x 31.7 gal/min (120 L/min) |
| Max. relief pressure, implement | 4,975 psi (34.3 MPa) | |
| Max. relief pressure, power boost | 5,410 psi (37.3 MPa) | |
| REFERENCE ARM | Arm length | 9 ft 6 in (2.9 m) |
| Arm digging force, ISO - Power boost | 15,737 lbf (70 kN) | |
| WORKING RANGES | Max. digging depth | 19 ft 3 in (5,870 mm) |
| Max. digging reach at ground level | 28 ft 3 in (8,620 mm) | |
| Max. digging depth at 2.4 m (8 ft) level bottom | 18 ft 7 in (5,670 mm) | |
| Max. dumping height | 29 ft 8 in (9,040 mm) | |
| Max. digging height | 21 ft 7 in (6,590 mm) | |
| Max. vertical wall digging depth | 16 ft 11 in (5,160 mm) | |
| BUCKET PERFORMANCE | Bucket capacity | 0.47 yd3 (0.36 m³) |
| Bucket digging force, ISO - Power boost | 21,784 lbf (96.9 kN) | |
| SERVICE CAPACITIES | Fuel tank | 65 gal (245 L) |
| Engine oil | 2.9 gal (11 L) | |
| Final drive(each) | 0.66 gal (2.5 L) | |
| Swing drive | 0.79 gal (3.0 L) | |
| Cooling system | 5.5 gal (21 L) | |
| Hydraulic reservoir | 42.3 gal (160 L) | |
| DEF tank | 4.5 gal (16.9 L) | |
| SWING SYSTEM | Swing speed | 12.9 rpm |
| Swing torque | 59,995 lb - ft (80,800 N·m) |
Product Features
- POWER THROUGH ANY TASK -The 915E touts options for auxiliary hydraulic piping include bi-directional variable high flow lines, an additional line for rotating attachments and also a single acting line. The quick coupler further ensures you get the most out of your machine by easily switching between a wide range of attachments to suit any application.
-
Powerful Performance- The 915E's Cummins QSB4.5 engine produces net power of 121 hp and torque of 347 lb.-ft. LiuGong has harnessed this power to the job at hand and even the least experienced of operators will find they can work faster and complete more in less time.
-
Operator Friendly-Ergonomically designed controls, clear and informative displays, increased visibility, and exceptional comfort increases operator efficiency and safety. The 915E also includes seven percent larger glass surface area combined with a standard rear view camera which gives the operator a panoramic view.
-
Optimized Hydraulics-Where intelligence meets brute force, load-sensing hydraulics direct the engine's power to ensure hydraulic pump flow continually adjusts for smooth, quick and efficient operation.
-
Adjustable Seat And Joystick Control-The adjustable seat and joystick console move independently to accommodate the operator. Increased spacing between the armrest and nine different seat adjustments allow the operator more options to all foot and hand controls for maximum comfort.
